ZFP HiNET Repeater panel Multipath Network (includes network interface PCB) Surface mount

Context Plus·SKU: ZREP1S

Indicative Price

Excluding local taxes and shipping.

Multipath Network (includes network interface PCB) Surface mount

infoNo online payment — request a quote and our team sends pricing. Prices are indicative and exclude taxes & shipping.

Description

The Context Plus ZREP1S is an intelligent addressable ZFP network device that can be used as a traditional but compact repeater panel with added functionality. Includes a Z41 Touchscreen Control Module and ZHN ‘Hi-Net’ multi-path fault-tolerant network PCB. Housed in a stylish surface mounting plastic enclosure measuring just 214mm x 178mm x 70mm. Can be used to an enhance a building’s reception area and access points (locate your main ZFP panels out of sight and let our ZFP Compact Controllers add a touch of class to your surroundings). Full Access Level 2 functionality (silence, disable, reset, etc). Requires a separate EN54-4 boxed PSU such as our BF360-24 24V boxed PSU. Up to 64 Compact Controllers can be connected to a ZFP network (each controller classed as 1 network node).

Power requirements: Requires a separate EN54-4 PSU such as our BF360-24 24V boxed PSU.Indicators : Full-colour 480 x 272 pixel touchscreen; 16 LEDS (11 reserved for mandatory EN54 indicators).
Controls : Interactive touchscreen with menu sensitive buttons; 1 x keyswitch allowing direct access to Access Level 2. Keyswitch requires S-KEY fire panel key.
Product dimensions: (mm) 214 W x 178 H x 70 D mm. Surface mounting.
Construction & finish: Plastic detachable lid and back box. RAL7035.
IP Rating: IP41.
Weight:1.27kg (unpacked).
Operating conditions/temperature: -5ºC to +40ºC. Max. relative humidity 95% non-condensing.
Notes: Up to 64 ZFP Compact Controllers can be connected to a ZFP ‘Hi-Net’ Network. See Instructions for further details.

Manufacturer technical information

Technical Specifications

Dimensions (W × H × D)214 × 178 × 70 mm
IP ratingIP41
Operating temperature-5 to +40 °C
Power supplySeparate EN54-4 PSU required
Weight1.27 kg
