Edwards SIGA-CC1S (Synchronization Module)

Edwards·SKU: SIGA-CC1S

Indicative Price

Excluding local taxes and shipping.

Synchronization Module Intelligent Analog Device

infoNo online payment — request a quote and our team sends pricing. Prices are indicative and exclude taxes & shipping.

Description

Edwards SIGA-CC1S Synchronization Module Intelligent Analog Device

The actual operation is to set up the code, which will be downloaded from the loop during system configuration.

The synchronization module make a signal for the power riser selector to relieve signals in multiple zones requires. Also, connect to a command from the loop controller, supervised B signal, or telephone to their respective power. For example, the power inputs to polarized 24 Vdc to operate audible and visible signal appliances or 25 and 70 VRMS to operate audio evacuation speakers and firefighters telephones.

This is configure for telephone circuits. There is the Edwards SIGA-CC1S Synchronization Module that generates their own ring-tone signal, to remove and separate ring-tone circuit. Signature modules transmit information to the loop regarding their circuit locations with respect to other Signature devices on the wire loop.

All decisions are make at the module to permit lower communication speed to increase the control panel response. Also, keep additional time and less sensitivity to line noise and loop wiring properties; twist or shield wires. The SIGA-CC1S is ideal for locations that only one module is require. The I/O and data loop connections is create separately to each module.

Otherwise, the compatibility of this module with GE Security’s Loop Controller makes operates under EST3 and QuickStart Loop. The module is able to identify and automatic self-diagnosis when it is not able to operate and causes a troubling message. The maintenance program shows the current state of each module and other pertinent messages. The single modules will turn off temporarily, from the control panel.
