Multi-Criteria Detectors
Advanced AXIS-OHX Axis EN Multi-Sensor Detector W Isolator
Advanced Electronics·SKU: AXIS-OHX
Indicative Price
Excluding local taxes and shipping.
Axis EN Multi-Sensor Detector W Isolator
infoNo online payment — request a quote and our team sends pricing. Prices are indicative and exclude taxes & shipping.
Description
The Axis-OHX combines smoke and temperature measurements on compatible Axis EN fire alarm systems. Its algorithms use both sensing elements, with nine operating modes and a chamber designed to limit airborne contamination. A bidirectional short-circuit isolator and two bi-colour status LEDs are built in. Device configuration uses the manufacturer programming tool or supported panel functions.
Technical Specifications
| Average standby current | 85 µA at 24 VDC |
|---|---|
| Detection method | Smoke and heat multicriteria |
| Dimensions (H × diameter) | 58 × 100 mm |
| IP rating | IP40; IP42 with specified base gasket |
| Loop voltage | 18 to 40 VDC; operation down to 15 V without LED indication |
| Operating modes | 9 |
| Operating temperature | -10 to +55 °C |
