Simplex 4906-9230 (True Alert Multi-Candela Horn Strobe, Ceiling-Mount)
Simplex·SKU: 4906-9230
Indicative Price
Excluding local taxes and shipping.
rueAlert Multi-Candela Horn Strobe, Ceiling-Mount, 15/30/75/110cd, White
infoNo online payment — request a quote and our team sends pricing. Prices are indicative and exclude taxes & shipping.
Description
The Simplex 4906-9230 is a white ceiling-mounted TrueAlert addressable horn/strobe. A compatible IDNAC circuit provides power, supervision and individual appliance control. Its xenon strobe offers selectable intensity, while the horn supports panel-selected alarm patterns and high or low output. Magnet-test diagnostics can identify the appliance and exercise its audible and visible outputs.
Technical Specifications
| Control | Addressable IDNAC SLC |
|---|---|
| Horn patterns | Temporal, March Time (60 or 120 BPM), continuous |
| Housing colour | White with red FIRE lettering |
| Mounting | Ceiling |
| Strobe flash rate | 1 Hz, synchronised |
| Strobe intensity | 15, 30, 75 or 110 cd |
