Mircom MIX-M500MAP (Monitor Module) 1.png
Monitor Modules

Mircom MIX-M500MAP (Monitor Module)

Mircom·SKU: MIX-M500MAP

Indicative Price

Excluding local taxes and shipping.

Mircom MIX-M500MAP Monitor Module is a standard-sized module that supervises either a Style D (Class A) or Style B (Class B) circuit of dry-contact input devices.

infoNo online payment — request a quote and our team sends pricing. Prices are indicative and exclude taxes & shipping.

Description

The MIX-M500MAP monitors normally open dry-contact devices on a compatible Mircom intelligent system. Its supervised initiating circuit uses Class A or Class B wiring. Rotary decade switches set the module address; Advanced Protocol and legacy CLIP operation depend on the control-panel configuration. A panel-controlled LED indicates module status.

Manufacturer product information

Technical Specifications

Dimensions (H × W × D)4.5 × 4 × 1.25 in
End-of-line resistor47 kΩ
Input circuitClass A or Class B
Operating temperature0 to 49 °C
Operating voltage15 to 32 VDC
