Edwards SIGA-MM1 (Monitor Module) 1.png
Monitor Modules

Edwards SIGA-MM1 (Monitor Module)

Edwards·SKU: SIGA-MM1

Indicative Price

Excluding local taxes and shipping.

Monitor Module – UL/ULC Listed

infoNo online payment — request a quote and our team sends pricing. Prices are indicative and exclude taxes & shipping.

Description

Edwards SIGA-MM1 — Signature Series addressable monitor module with one Class B normally open dry-contact input.

This is the standard interface between a Signature loop and anything that closes a dry contact: waterflow switches and valve tamper switches. The address is assigned electronically by the loop controller, so there are no dials to mis-set, and a downloaded personality code sets circuit behaviour — code 3 is active, normally open, non-latching Class B.

  • Operating voltage: 15.20 to 19.95 VDC from the SLC
  • Current: 300 µA standby, 450 µA activated
  • EOL resistor: 47 kΩ, UL/ULC listed; IDC resistance 50 Ω max.
  • SLC Class A Style 6 or Class B Style 4
  • Mounts to a 2-1/2" (64 mm) deep single-gang box, or a 4" square 1-1/2" (38 mm) deep box with single-gang cover
  • 32°F to 120°F (0°C to 49°C); UL 864

The MM1 monitors one circuit only; for two independent inputs order the SIGA-MM2. It does not support conventional smoke detectors. Replace the shipping test resistor with a listed 47 kΩ EOLR.

Supplier product page
