Edwards G1RF-HD (Alarm Horn)

Edwards·SKU: G1RF-HD

Indicative Price

Excluding local taxes and shipping.

Fire Alarm Horn

infoNo online payment — request a quote and our team sends pricing. Prices are indicative and exclude taxes & shipping.

Description

Edwards G1RF-HD — Genesis temporal-tone alarm horn, red, with FIRE marking. Horn only, no strobe.

The suffix decodes as G1 (Genesis one-gang signal), R (red housing), F (FIRE lettering) and HD (temporal horn, selectable high/low dB). Installers reach for a horn-only Genesis where audibility must be reinforced but visible coverage is already satisfied by nearby strobes, and where the device must drop into a one-gang box with no trim plate. Unlike the strobe models, horn-only units may be ceiling-mounted.

  • Field-selectable high (default) or low dB, and temporal (default) or steady tone
  • UL 464 reverberant at 24 Vdc, 10 ft: 84.4 dBA temporal high, 88.6 dBA steady high; 79.4 and 83.5 dBA on low
  • UL max RMS current at 24 Vdc: 36 mA high, 27 mA low (24 Vfwr 69 mA and 52 mA)
  • 16–33 Vdc filtered or 16–33 Vfwr unfiltered; #18–#12 AWG

This model has no visible signal and cannot satisfy a strobe requirement — specify G1RF-HDVM if a candela-rated device is needed. The white-housing equivalent is G1F-HD.

Supplier availability note: discontinued/legacy. Confirm availability before ordering.
