Autronica 116-BSD-310 Loop Driver Module

Autronica·SKU: 116-BSD-310

Indicative Price

Excluding local taxes and shipping.

Loop Driver Module

infoNo online payment — request a quote and our team sends pricing. Prices are indicative and exclude taxes & shipping.

Description

The BSD-310 loop driver connects one detection loop to an AutroSafe control panel or controller. Each loop supports up to 127 loop units and is monitored for breaks and short circuits. The rail-mounted module is automatically addressed. This is the standard BSD-310; the higher-current BSD-311 and hazardous-area /N variants are separate models.

Manufacturer product information

Technical Specifications

Detection loops1
Dimensions95 × 89 × 32 mm
Loop output voltage24 VDC
Maximum loop output current100 mA
Maximum loop units127
Operating temperature-20 to +70 °C
